Electrostatic Field Lines And Faraday #1
by Ted Kinsman
Title
Electrostatic Field Lines And Faraday #1
Artist
Ted Kinsman
Medium
Photograph - Photograph
Description
Electrostatic field lines around two point charges and a cylinder. The left point is charged to -30,000 volts while the right point has a potential of +30,000 volts. Of special importance is the lack of fields showing inside the cylinder, which acts as a Faraday cage, shielding the enclosed area from any external electrical fields. This is the classic case of no electrical fields inside an electrical conductor. Part of a series showing different charging conditions. The electric fields are shown by placing the two charged objects in a pan filled with cooking oil and pepper flakes, which align in the electric field, allowing visualization of the field.
Uploaded
June 2nd, 2013
